SUNFAR C300 21
C300 series of non-sensor current vector-control inverter manual
Parameters’
Types
Function Code Name Setting range
Minimum
Setting
Manufacture
Setting
Modify
Limit
F0. 13
Acc/Dec initial section of
S curve
10 .0~ 50.0 （%） 0.1 20.0 ★
F0. 14
Acc/Dec ascend/decline
section of S curve
10.0 ~ 80.0 （%） 0.01 60.0 ★
F0. 15 Reserved
F0. 16 Carrier wave frequency 1.5~ 12.0 KHz 0.1 6.0*
F0. 17 Carrier wave characteristics
The first part of LED (form right to left):
Reserved
The second part of LED (form right to
left):
0：The relation between out current and
Carrier wave is off.
1：The relation between out current and
Carrier wave is on.
The third part of LED (form right to left):
0：The relation between module temp
and Carrier wave is off.
1：The relation between module temp
and Carrier wave is on.
The third part of LED (form right to left):
0：The relation between out frequent and
Carrier wave is off.
1：The relation between out frequent and
Carrier wave is on.
1 1110
Basic operation parameter unit
F0. 18 Parameter write-protect
1：Forbid to modify all parameter, except
F0.2 and F0.18
2：Forbid to modify all parameter, except
F0.18
1 0
Primary
applied
paramete
r unit
F1. 0
Type of V/F Curve
(Parameters [F1.0]～
[F1.13] is only under the
control mode
that is [F0.0]＝0,valid.)
0：Constant torque curve
1：Low-freq. torque curve 1
2：Low-freq. torque curve 2
3：V/F user-defined curve
1 0 ★
