C300 series of non-sensor current vector-control inverter manual
Parameters’
Types
Function Code Name Setting range
Minimum
Setting
Manufacture
Setting
Modify
Limit
F3.4 Output terminal（OC）
1
0
F3.5
TA, TB and TC of relay
contacts（TA、TB、TC）
0：In the running；
1：Frequency reaching；
2：Freq. level detection signal FDT；
3：Over-loading alarm；
4：External fault halt；
5：Output frequency reaches the
upper-limit；
6：Output frequency reaches the
lower-limit；
7：Running in zero speed；
8：Inverter will stop when under voltage；
9：PLC stage is end of run；
10：PLC periodic is end of run；
11：Reserved；
12：Setting value of counter arrives；
13：Designated value of counter arrives；
14：Reserved；
15：Reserved；
16：Inverter fault；
17：Restrictions on wobble freq. of the
upper and lower limit freq.
18：Reserved；
1
16
F3.6
Frequency reach the
checkout amplitude
0.0~20. 00Hz 0. 01 5.00
F3.7 FDT setting 0.0~ the upper limit freq. 0.01 10.00
F3.8 delay time of FDT output 0.0~200.0s 0.1 2.0 ★
F3.9 level of over-loading alarm 50~200（％） 1 110
F3.10
delay time of
over-loading alarm
0.0~20.0s 0.1 2.0 ★
Auxiliary running parameter unit
F3.11 Reserved
