28 SUNFAR C300
C300 series of non-sensor current vector-control inverter manual
Parameters’
Types
Function Code Name Setting range
Minimum
Setting
Manufacture
Setting
Modify
Limit
F4.0 Start mode
0：Routine mode
1：Detect speed and restart
1 0 ★
F4.1 Start frequency 0.0～10.00Hz 0.01 0.5
F4.2 Start frequency duration 0.0～20.0 S 0.1 0.0 ★
F4.3 Stop mode
0：Decelerate mode
1：Uncontrolled stop
1 0
F4.4
Initial freq. of DC braking
when stopping
0.0～50.00Hz 0.01 3.00
F4.5
Waiting time of
DC braking when stopping
0.0～5.0 S 0.1 0.1
F4.6
Action time of DC braking
whenstopping
0.0～20.0 S 0.1 0 ★
F4.7
DC braking current when
stopping
0.0～100（％） 0.1 50.0
F4.8
Running threshold of zero
freq.
0.0～100.0Hz 0.01 0.0
F4.9 Return different of zero freq. 0.0～50.00Hz 0.01 1.00
F4.10 Jog frequency 0.0～the upper limit freq. 0.01 10.00
F4.11 Acc torque level 110～200（％） 1 160
F4.12 Braking torque lever 10～150（％） 1 80
Auxiliary running parameter unit
F4.13
Motor over-loading
protection coefficient
50～110（％） 1 100
