8 Web Interface User Manual
46
Data Type
Description
YT
Remote regulating
Step 3 Open the sheet "Cfg Para" of the IEC104 forwarding point table to view and
set the addresses of the five types of data. The addresses shown in the
following table are default ones and can be modified according to actual
situation.
Tab. 8-4 Cfg Para tab parameters
Data Type
YX
YC
YM
YK
YT
Bngr Addr
1
16385
15221
15271
15000
Step 4 Open the sheets such as inverter, energy meter, Meteo Station, and
Logger1000, to set corresponding measuring point data.
Data
Type
DataID State Invert Coefficient Uint Data Name
YC
1
Y
N
1000
W
P
YC
2
Y
N
1000
Var
Q
YX
3
Y
Y
1
NA
On-grid
YX
4
Y
N
1
NA
Off-grid
YM
5
Y
N
1
kWh
E-Daily
YK
6
Y
N
1
NA
Power On / Off
YT
7
Y
N
1
kW
P-Set
YT
8
Y
N
1
Var
Q-Set
Parameter
Value
Description
Data Type
-
Data type
Data ID
-
Data type
State*
Y
Data is uploaded to the background via the IEC104
communication protocol
N
Data is not uploaded to the background
Invert*
Y
Negate, 0 is 1, and 1 is 0, available for telesignalling only
N
No negate, 0 is 0 and 1 is 1
Coefficient* -
Coefficient, available for telemetry, remote pulse, and
remote regulating only
Uint -
Unit, available for telemetry, remote pulse, and remote
regulating only
NA indicates no unit
Data Name
-
Data name in multiple languages
Note: * indicates that the parameters should be set according to onsite conditions.
Step 5 Open the sheet "Device List" of the IEC104 forwarding point table to sort the
devices.
