Step 2 Install the charging cable bracket.
1 Hold the charging cable bracket in the desired position on the wall and mark the posi-
tions of the drill holes.
2 Drill holes at the marked positions using a hammer drill.
3 Insert the dowel into the hole.
4 Place the charging cable bracket on the wall, and tighten the screws to secure the charg-
ing cable bracket using a screwdriver.
It is recommended that the charging cable bracket be positioned at the lower right
side of the charger, about 20 cm away from the charger. The distance shall be ad-
justed according to the actual situation.
User Manual 2 Installation

Sungrow AC011E-01 Specifications

General

Model	AC011E-01
Category	Battery Charger
Output Power	11 kW
Frequency	50/60 Hz
Operating Temperature	-25°C to +60°C
Protection	Overvoltage, Overcurrent, Short Circuit, Over Temperature
Communication	RS485/CAN
