45
1. Scale plate adjustment
Adjust the scale plate② prior to sewing for proper adjustment of scales in line with sewing conditions.
(The default is Scale 2 of 10mm.)
[Figure 97]
②
②
①
③
21. Adjusting the eyelet button hole device [(SPS/D-B1201M(HE)]
A. Loosen the screw①.
B. The scale plate② can be horizontally adjusted.
There are five scale choices from 0 to 4.
Select a scale in line with sewing materials.
(See Table 1 below for proper selection of a scale.)
Locate the scale plate② at the scale of choice.
C. Tightly fasten the screw① after adjustment.
[Figure 98]
①
4 0
