SunStar SPS/C-B1201 SERIES User Manual

20
7) Installation and control of the option wiper (HA type)
A. Mount the wiper base plate with a screw as shown in
the Figure.
B. Fix the wiper base onto the opposite side with two
fixing screws as shown in the Figure.
C. Link the connector located at the solenoid with the
connector from the arm.
[Figure 25]
[Figure 26]
[Figure 27]
