Preparations before using the machine
1) Lubrication
A. Check the amount of oil left in the oil tank installed on
the arm before lubrication.
B. Check the remaining amount of oil from the gauge
window of the oil tank on the bed, then supply a
sufficient level of oil through the lubrication hole on the
bed cover.
C. Pour oil into the lubrication hole in the upper part of
the arm.
[Caution]
Be sure to supply oil if the machine is being used for the
first time or has been left unused for a long time.
[Figure 41]
[Figure 42]
[Figure 43]
