11
A. Fix the oil tub holder①, oil tray②, control box③ and
power switch④ onto the table.
C. In case of SPS/D-B1201 series, attach the safety
switch supporting rubber① to the table.
44
Installation
1) Machine installation conditions
A. Do not use the machine where the voltage is over or under 10% of the rate current to prevent accidents.
B. For safe operation, use the machine under the following conditions.
Room temperature when the machine is in use: 5℃~40℃
Room temperature when the machine is not in use: －10℃~60℃
C. Humidity: 20~80% (relative humidity)
2) Electric installation conditions
A. Voltage
The voltage must be between within ± 10% of the rated current.
The frequency must be within 1% range of the rated current frequency (50/60Hz)
B. Electromagnetic waves
Use separate power for products with strong electromagnetic waves or high frequency. Keep the sewing machine
away from them.
C. Always use low voltage when mounting accessories or supplementary devices on the control box.
D. Do not spill water or coffee into the control box or motor.
E. Do not drop the control box or motor.
[Figure 1]
3) Safe installation of the tables
[Figure 2]
B. Attach the bed cushion rubber① to the table.
①
[Figure 3]
①
②
To Next Page
