Suntex PC-3310 - 1 Specification

1.Specification
Model
PC-3310
Measurement modes pH/ORP/Temp
Ranges
pH -2.00~16.00pH
ORP -1999~1999mV
TEMP
-30.0~130.0ɗ
Resolutions
pH 0.01pH
ORP 1mV
TEMP
0.1ɗ
Accuracy
pH ±0.01pH (±1 Digit)
ORP ±0.1% (±1 Digit)
TEMP
±0.2ɗ (±1 Digit)
Equipped with temperature error modification function
Temperature
Compensation
NTC30K / PT1K auto temperature compensation
Manual adjustment temperature compensation
Calibration mode
TECHİġNISTİġAny Buffers up to three point calibration
Ambient Temp.
0~50ɗ
Storage Temp.
-20~70ɗ
Input Impedance > 10
12
ȍ
Display
Large LCM with sensitization sensor for auto/manual illumination
function & contrast function.
Language Available for English, Traditional Chinese, Simplified Chinese
Analog output 1
Isolated 0/4~20mAcorresponding to main measurement,
max. load ȍ
Analog output 2 Isolated 0/4~20mA corresponding to Temp., max. load 50ȍ
Settings
Contact RELAY ON/OFF contact, 240VAC 0.5A Max.(recommended)
Activate Hi/Lo. Hi/Hi/. Lo/Lo selectable two limited programmable, ON/OFF
Wash RELAY contact, ON 0~99min. 59sec./ OFF 0~999hr 59min.
Voltage output
DC±12V炻1W Max. for PH-300T(Optional)
Protection IP65
Power supply
100V~240VAC±10%炻6W Max.炻50/60Hz
Installation Wall / Pipe / Panel Mounting
Dimensions 144mm × 144mm × 115mm (H×W×D)
Cut off Dimensions
138 mm × 138 mm (HuW)
Weight 0.8 Kg
