OPERATION & MAINTENANCE MANUAL SWDE120B-3
16
2.3 Electric Control Section of Cab
FIG. 2.3.1 Electrical Layout in Cab
Bus panel, Rocker switch
Emergency stop, white light, yellow light, buzzer, ignition lock, throttle, locked, mode selection, air supply
Display screen
Fan, grease lubrication, horn, rod discharge/upper clamp, dust hood/lower clamp, radio, air conditioner panel
