SUNWARD SWDE120B-3 - PILOT LEVER AND SWITCHES CONTROL

OPERATION & MAINTENANCE MANUAL SWDE120B-3
28
Panel F
No.
Part
Button Code
Indicator Light Status
Remark
1
Fast Travel Speed
F1
Green
2
Oil Cooling
F2
Green
3
Warning Light
F3
Green
4
Pulse Power
F4
Green
5
Water Heating
F5
Yellow
6
Oil Heating
F6
Yellow
7
Dedusting Water
Pump
F7
Green
Optional
8
Standby
F8
Green
Input
and
Output
Control
of Bus
Panel
Function Switch
Corresponding Output
Swing Rod Limit
Retract
Press down the switch, the indicator light is on and the swing rod
limit block retracts.
Swing Rod Limit Extend
Press down the switch, the indicator light is on and the swing rod
limit block extends.
Left Front Outrigger
The valve opens, and the indicator light is on, the valve closes
and the light is off.
Right Front Outrigger
The valve opens, and the indicator light is on, the valve closes
and the light is off.
Left Rear Outrigger
The valve opens, and the indicator light is on, the valve closes
and the light is off.
Right Rear Outrigger
The valve opens, and the indicator light is on, the valve closes
and the light is off.
Diesel/Electrical
Conversion
Press down the switch for 3 seconds, the indicator light is always
on, this is the diesel engine mode; The indicator light is off, this is
the electric mode.
Transformer Cooling
The light is on and the transformer cooling is enabled.
Hydraulic Oil Cooling
Switch
When hydraulic oil is more than 60°C, “Hydraulic oil heat up too
fast, the cooling fan start automatically” is shown on the meter.
And the valve open automatically, the indicator light is always
on. If hydraulic oil is lower than 50°C, valve is off and the
indicator light is off; At this time, turn on and off the switch for 2
seconds, the forced valve open and the light flickers every 1
second, and then press down that again, the forced valve close
and the light is off.
Warning Light Switch
Start the engine and enable the pilot, the warning light is on
automatically without sound. When reversing, the sound and light
are turned on automatically. Press down the switch to close the
warning light, and press down that again to enable that. Any
function is enabled, the indicator light on the panel is on, and
otherwise, it’s off.
