396-4412Y1 QuickDraw 3000 Operator’s Manual 61 Revised 02/20/2020
Accessory Kit List (Harnesses)
Item Number Item Description
208-05-4312Y1 QuickDraw 3000 Wiring Harness
208-05-4313Y1 QuickDraw 3000 10 Ft Extended Wiring Harness
208-05-4314Y1 QuickDraw 3000 25 Ft Extended Wiring Harness
208-05-2414Y1 QuickDraw Pump Stop Wiring Harness Set (contains 2 harnesses)
208-05-2430Y1
QuickDraw Electric Start Gas Engine 12 Volt Supply Harness (does
not start pump)
208-05-2431Y1 QuickDraw electric motor drive pump start harness
208-05-3237Y1 78" Ethernet RJ45 to M12 Adapter Cable
208-05-3944Y1 QuickDraw Gas Engine Push Button Start
208-05-3955Y1 QuickDraw Electric Pump Start-Stop Harness Set
208-05-4022Y1 Optima Battery 8022-091 75/25 RedTop Starting Battery
208-05-various Many more specialty harnesses
The accessory harnesses listed below all attach to the main QuickDraw harness, 208-05-2326Y1.
Power harness extensions from vehicle baery
480 MP Extension Harnesses 206-02-xxxxxx
QuickDraw has an internal battery to guarantee adequate power while running. However, it MUST be
charged from the vehicle electrical system. Each QuickDraw includes a 20’ power harness (205-
2213Y1) to attach to the vehicle battery. If mounted further from the vehicle battery than 20’ and/or
crossing a trailer hitch, customer will need an extension harness.
Power harness to supply electric start gas engine transfer pump
QuickDraw Electric Start Gas Engine 12 Volt Supply Harness 208-05-2430Y1
The QuickDraw battery can be used to supply power for an electric start gas engine transfer pump.
There is a 480 MP connector on the QuickDraw harness that attaches to this harness. It makes wiring
an electric start transfer pump fast and easy without the need for an extra battery or wiring back to the
vehicle battery. The harness is 15 feet long.
Pump Stop Harness (for electric or gas engine driven pump)
QuickDraw pump stop harness 208-05-2414Y1
QuickDraw has the ability to turn off the transfer pump. This harness provides a connection to a relay
in the QuickDraw harness. The relay is normally closed, it then opens for 10 seconds when the pump
is commanded to stop. Connect the harness to any wire on the engine that requires power for the
pump to run. Comes with 4 mm bullet terminals which fit some pumps on the market.
Pump Start Harness (for electric driven pumps only)
QuickDraw electric motor drive pump start harness 208-05-2431Y1
QuickDraw can start an electric motor driven transfer pump. This harness provides a connection to a
relay in the QuickDraw harness. The relay is normally open, it then closes for 1 second when the
pump is commanded to start. Recommended for use along with the pump stop harness above.
