INSTALLATION AND TRANSPORT
8 MJB4 - Installation and Transport Rev02 01-06
2
Power Data:
Specifications for Qutomatic Circuit Breakers:
Supply Media:
The machine has connections for pneumatic hoses
with a 6mm outer diameter or connections for pneu-
matic hoses with a 1/4 inch outer diameter. Hose
couplings for supply media connections are not in-
cluded.
Standard with
CPC200:
300 VA ; 230 V AC ±10% ;
50/60 Hz
Standard with
CPC350:
500 VA ; 230 V AC ±10% ;
50/60 Hz
Standard with
CIC1200:
1200 VA ; 230 V AC ±10% ;
50/60 Hz
Power overview: CPC200 = 300 VA
CPC350 = 500 VA
CIC1200 = 1200 VA
Machine = 250 VA
Ext. power =250 VA (standard)
Max. connected load = 16 A
Power cord: grounded 3-wire cable;
3.0 m
V(AC) input
1
1. The CIC1200 only works with 230 V (AC) current
100-240
F1(A) CPC200 4
F2(A) electronics 2
F3(A) 7.5
Nitrogen: ca. 1.5bar, 30 - 45 psi;
Consumption: Depends on lamp model; see
the table ”Settings for lamp
cooling and lamp housing
extraction” in section 1.1.
"Prerequisites for Installation".
! Warning ! Use dry nitrogen only
Vacuum: -0.8 bar manometer reading
(equals 0.2 bar absolute)
Compressed air:
Without base: ca. 5.5 bar, 75 psi
With base: ca. 7.0 bar, 105 psi
Consumption: ca. 1.0 m
3
/h, 35 scf/h
! Warning ! Water, oil and dust particles
must be removed from the
compressed air supply
system.
Table 1: Settings for lamp cooling and lamp housing extraction
Notes
Exposure lamp [W] 200
Osram
350
Osram
350
Ushio
500
Ushio
Nitrogen
Main pressure
[bar] 1.5 1.5 1.5 1.5
Nitrogen lower lamp
base
[l/h] 180 180 120 80 Must be set by
service technician
Nitrogen upper lamp
base
[l/h] - - - 200 Must be set by
service technician
Nitrogen
Shutter
[l/h] 260 260 260 260 Must be set by
service technician
Diameter
Extraction
[mm] - - - 100
