APPENDIX MJB4
MJB4 - Appendix Rev02 01-06 63
4
4.1. Schematics of the Electronic System MJB4
Item Description Assembly-No. Schematic Page
1 Wire list, R06 190675 Sheet 1 65
2 Wire list, R06 190675 Sheet 2 67
3 Wire list, R06 190675 Sheet 3 69
4 Wire list, R06 190675 Sheet 4 71
5 Wire list, R06 190675 Sheet 5 73
6 Wire list, R06 190675 Sheet 6 75
7 Wire list, R06 190675 Sheet 7 77
8 Overview of cables 189886 (OZ) 79
9 Cable W1: Unit U1 - SPS OD232 189058 189872 81
10 Cable W2: Pneumatic I 189060 189873 83
11 Cable W3: Pneumatic II 189061 189874 85
12 Cable W4: Unit U1 - VCC PLC 189901 189902 87
13 Cable W5: Unit U1 - PLC ID211 190304 189876 89
14 Cable W6: Unit U1 - PLC AD081 190335 189877 91
15 Cable W7: Unit U1 - Interlock N
2
CIC1200 189505 189903 93
16 Cable W8: VCC Unit U1 189897 189898 95
17 Cable W9: Signals X2 - U1 190336 189875 97
18 Cable W10: VCC Touchscreen 189899 189900 99
19 Cable W11: Illumination 191495 191494 101, 103
20 Cable W12: Unit A4 Splitterbox - U1 191512 191513 105
21 Cable W13: Sensor 1.1C1 191268 191981 107
22 Cable W14: Sensor 1.3C1 191268 191982 109
23 Cable W15: Sensor 00C3 150055 191983 111
24 Cable W16: Sensor 00C1 150055 191984 113
25 Cable W17: Sensor 00C2 150055 191985 115
26 Cable W18: Sensor 9/C1 150055 191986 117
27 Cable W19: PLC SCU41 - CIC1200 189504 189907 119
28 Cable W20: Elektronic ON key 2S2 189889 189878 121
29 Cable W21:
Touchscreen Port B - PLC CJ1M
189528 189904 123
30 Cable W22: Touchscreen Port A 189905 189906 125
31 Cable W23: Unit U2 - Unit U1 183971 188501 127
32 Cable W24: Unit U3 - Unit U1 188502 190053 129
To Next Page
