APPENDIX MJB4
64 MJB4 - Appendix Rev02 01-06
4
33 Power supply 186661 189826 131
34 PLC 187246 190672 133
35 Sensors manipulator 185452 190674 135
36 Phönix SACB-6/3-L-M16 (U2 manipulator) 190669 190670 137
37 Sensors lamp house 187260 190673 139
38 Phönix SACB-6/3-L-M16 (U3 lamp house) 190669 190671 141
39 Wiring diagram distributorplate MJB4 189489 143
40 Components side printing distributorplate
MJB4
189489 145
41 Layout distributorplate MJB4 189489 147
Item Description Assembly-No. Schematic Page
