OPERATION OF THE MJB4
MJB4 - Operation Rev02 01-06 37
3
3.8.3. Loading, Adjusting and Exposing the Substrate
Menu in the Display Button Strokes in the Display
MAIN MENU LOAD SUBSTRATE
LOAD SUBSTRATE
Load the mask holder with the mask
Pull out the slide and load the chuck
Place the substrate on the chuck
Insert the slide completely
Raise the substrate with the contact lever (WEC)
WARNING! Microscope pivots downwards
EXPOSE
Separation lever set to adjusting position
SUBSTRATE ADJUSTMENT
Adjust substrate
Separation lever set to adjusting position for
exposure
EXPOSE CHECK ADJUSTMENT
For checking the adjustment in the selected
exposure program
EXPOSE
For exposing the substrate
WARNING! Microscope pivots upwards
Mirror housing and microscope move towards the
operator.
UNLOAD SUBSTRATE
Pull the contact lever back, pull out the transport
slide and load the substrate
MAIN MENU
