MANUAL TRANSAXLE (M13 ENGINE) 7A2-11
Vehicle Speed Sensor (VSS) Removal and
Installation
Removal
1) Disconnect negative cable at battery.
2) Disconnect VSS coupler (1).
3) Remove VSS (2).
Installation
1) Apply oil to new O-ring (1) and then install VSS to transaxle.
2) Connect VSS coupler (1).
3) Connect negative cable at battery.
(1)
