A-96.250.511 / 091120
AMI Turbiwell
Product Description
14
2.1. Instrument Specification
Note:
• If the maximum sample temperature of 45 °C is exceeded for a
short time, the instrument will not be damaged.
• Swan recommends that the sample temperature is no more
than 20 °C above ambient temperature. With increasing
temperature difference condensation will form to a higher
extent, but the measurement will not be affected. However, it is
possible that a temperature difference significantly higher than
20 °C will cause condensation directly on the optics, which can
lead to incorrect measurements.
Power Supply AC variant:
DC variant:
Power consumption:
100–240 VAC (±10%)
50/60 Hz (±5%)
10–36 VDC
max. 35 VA
Transmitter
Specifications
Housing:
Range of operation:
Storage and transport:
Humidity:
Display:
aluminum housing with a protection
degree of IP 66 / NEMA 4X
-10 to +50 °C
-30 to +85 °C
10–90% rel., non condensing
backlit LCD, 75 x 45 mm
Sample
Requirements
Flow rate:
Sample temperature:
Inlet pressure:
Outlet pressure:
approx. 20–60 l/h (flow rate through mea-
suring chamber: approx. 10–15 l/h)
1–45 °C (sample temperature max. 20 °C
over ambient temperature)
1–10 bar with flow controller option
pressure free
On-site The analyzer site must permit connections to:
Requirements Sample inlet:
Sample outlet:
Nozzle diam. 10 mm
2 drains diam. 16 mm, tubing 15 x 20 mm,
which must end in a pressure free waste of
sufficient capacity.
