A-96.250.511 / 091120
AMI Turbiwell
Program Overview
84
8.5. Installation (Main Menu 5)
Sensors Sensor type 5.1.1* * Menu numbers
5.1* Dimension 5.1.2*
Flow Flow measurement 5.1.3.1*
5.1.3* Slope 5.1.3.2*
Offset 5.1.4
Signal Outputs Signal Output 1 & 2 Parameter 5.2.1.1 & 5.2.2.1*
5.2* 5.2.1* & 5.2.2* Current Loop 5.2.1.2 & 5.2.2.2*
Function 5.2.1.3 & 5.2.2.3*
Scaling Range Low 5.2.x.40.10*
5.2.x.40 Range High 5.2.x.40.20*
Relay Contacts Alarm Relay Alarm Alarm High 5.3.1.1.1*
5.3* 5.3.1* 5.3.1.1* Alarm Low 5.3.1.1.25
Hysteresis 5.3.1.1.35
Delay 5.3.1.1.45
Sample Flow Flow Alarm 5.3.1.2.1*
5.3.1.2* Alarm High 5.3.1.2.2*
Alarm Low 5.3.1.2.36*
Case Temp. high 5.3.1.4*
Case Temp. low 5.3.1.5*
Relay 1 & 2 Function 5.3.2.1 & 5.3.3.1*
5.3.2* & 5.3.3* Parameter 5.3.2.20 & 5.3.3.20*
Setpoint 5.3.2.300 & 5.3.3.300*
Hysteresis 5.3.2.400 & 5.3.3.400*
Delay 5.3.2.50 & 5.3.3.50*
Input Active 5.3.4.1*
5.3.4* Signal Outputs 5.3.4.2*
Output/Control 5.3.4.3*
Fault 5.3.4.4*
Delay 5.3.4.5*
