5.2. Measured Values and Symbols on the Display
Relay status, symbols
A RUN normal operation
HOLD input closed or cal delay: Instrument on hold (shows
status of signal outputs).
OFF input closed: Control/limit is interrupted (shows status
of signal outputs).
B ERROR Error Fatal Error
C Transmitter control via Profibus
D Time
E Process value
F Sample Flow
G Relay Status
upper/lower limit not yet reached
upper/lower limit reached
control upw./downw. no action
control upw./downw. active, dark bar indicates control intensity
motor valve closed
motor valve: open, dark bar indicates approx. position
timer
timer: timing active (hand rotating)
RUN
15:20:18
R1
R2
35.8 l/h
FNU
2.53
AB C
E
F
G
D
