A-96.250.511 / 091120
AMI Turbiwell
Maintenance
58
6.3. Cleaning the Degasser
Note: Use a soft brush and a mild detergent. Eliminate
calcareous depositions with a common household deliming agent
in standard concentration.
Cleaning To clean the degasser proceed as follows:
1 Stop sample flow.
2 Wait until the sample degasser is empty.
3 Turn the star knob [A] counter-clockwise to unscrew and remove
the degasser labyrinth form the base plate [G].
4 Remove the acrylic glass tube [F].
5 Loosen the counter nut [E] and remove both, counter nut and nut.
6 Remove the plates [C] from the guide rod.
7 Clean the plates and the acrylic glass tube with a soft brush and
mild detergent.
8 Eliminate calcareous depositions using a common household de-
liming agent in standard concentration.
9 Rinse the plates and acrylic glass tube with clean water.
10 Assemble alternately a plate with a white and a red distance
holder to the guide rod. Start with a white plate.
A
B
C
D
E
F
G
Star knob
Cover with guide pin holes
Plate
Degasser labyrinth
Counter nut
Acrylic glass tube
Base plate
