5.3. Software Structure
1
Messages
Operation
Maintenance
Diagnostics
Main Menu
Menu 4: Operation
Subset of menu 5 - installation, but process-related.
User relevant parameters that might need to be modi-
fied during daily routine. Normally password protected
and used by the process-operator.
Menu 1: Messages
Reveals pending errors as well as an event history
(time and state of events that have occurred at an ear-
lier point of time) and maintenance requests.
It contains user relevant data.
Menu 2: Diagnostics
Provides user relevant instrument and sample data.
Menu 5: Installation
For initial instrument set up by SWAN authorized per-
sons, to set all instrument parameters. Can be pro-
tected by means of a password.
Menu 3: Maintenance
For instrument calibration, service, relay and signal
output simulation and to set the instrument time.
It is used by the service personnel.
Installation
1.1
Message List
Messages
2.1
Interface
I/O State
Sample
Identification
Sensors
Diagnostics
4.1
Logger
Relay Contacts
Sensors
Operation
5.1
Interface
Miscellaneous
Relay Contacts
Sensors
Signal Outputs
Installation
Pending Errors
Maintenance List
3,1
Verification
Calibration
Maintenance
Simulation
Matching
Set Time
01.01.05 16:30:00
To Next Page
