WISE User Manual
Room settings
Each room has three modes:
• Automatic: Solar shading is controlled automatically based
on the temperature requirement. Schedule and override
button can override.
• Only schedule: Only the schedule and override button can
control solar shading.
• O: All sun shades are open.
Each solar shading node in a room can be set to one of the six
façades, but a node can only be assigned to one façade.
Even if a façade has sun, individual rooms on that façade may
have dierent angles. In cases where solar shading has more
limited sun, it's possible to set start/stop angles as well as sun
height limits for this particular solar shading. If this solar shading
does not have the sun, it will act as it would if the whole façade
did not have the sun. Other solar shades on the same façade
continue to work normally. Individual solar shades cannot be set
to greater start /stop angles and height than its façade. These
settings can be made under the WISE IORE, which controls the
relevant solar shading.
The solar shading’s node shows why it's down. Opening and
closing of the solar shading take place with some delay, the
length of this can be congured. This is to avoid the shade going
up and down too oen. There are also global delay system
settings for sun and cloud. The façade will not be considered
to have the sun until it has had the sun for a while. The same
applies when the sun disappears. This delay is also adjustable.
Adjustable room parameters in SuperWISE
Section Description Standard value Min. Max. Unit
Lowest user level
(read/write)
Function
Solar shading Function activated Automatic - - - Local/local Automatic, Only schedule or O
Solar shading Glare protection O - - - Installation/Installation Glare protection of or on
Solar shading
Insulation function,
mode
On - - - Installation/Installation On, O, Only unoccupied
