WISE User Manual
RTA group
Why RTA group?
In an RTA group, it is possible for several rooms to share the
setpoints from a WISE RTA. A room with WISE RTA can send its
information to other rooms in the group, and in this way several
rooms can use the same setpoint selector switch.
The group also controls the rooms’ occupancy mode, in the
same way that a WISE RTA does for one room. This means that
if the temperature setpoint has recently been changed via WISE
RTA, the rooms in the group are set to occupancy mode. It is
possible to set whether WISE RTA for the group is to control the
temperature setpoint, the fan speed for the fan coil or both. This
setting determines which values will be synched between the
rooms in the group.
Adjustable group parameters in SuperWISE
Section Description Standard value Min. Max. Unit
Lowest user level
(read/write)
Function
Group, RTA Settings Step 0.5 0.1 10 Celsius Installation/Installation
The dened step is the accuracy with which the user
can set the temperature setpoint on WISE RTA.
Group, RTA Settings Max. value 30 5 50 Celsius Installation/Installation
The highest level at which the user can set the temperature
setpoint on WISE RTA.
Group, RTA Settings Min. value 15 5 50 Celsius Installation/Installation
The lowest level at which the user can set the temperature
setpoint on WISE RTA.
Group, RTA Settings
Temperature
oset time
480 0 1200 Minutes Local/Local
Timer for how long the setpoint oset will apply
before it is reset, regardless of whether there is occupancy
or not.
0 = Never reset
Group, RTA Settings
Forced occupancy
time, RTA
0 0 1200 Minutes Installation/Installation
Timer that forces the room into occupancy for the set
time aer a setpoint oset has been made. Aer the set
time, the setpoint oset for non-occupancy is reset.
Group, RTA Settings
Fan speed,
return time
480 0 1200 Minutes Local/Installation
Timer for how long the fan speed change will apply before
it is reset, regardless of whether there is occupancy or not.
0 = Never reset
Group, RTA Settings Setpoint, mode 0 0 2 - Local/Installation
Temperature
Fan speed
Temperature and Fan speed
Group, RTA
Occupancy
Temperature
oset, cooling
1 0.5 10 Celsius Installation/Installation
Number of degrees above the set “Temperature setpoint”
that is permitted before cooling of the room occurs.
Group, RTA
Occupancy
Temperature
oset, heating
-1 -10 -0.5 Celsius Installation/Installation
Number of degrees below the set “Temperature setpoint”
that is permitted before heating of the room occurs.
Group, RTA
Occupancy
Temperature
setpoint
22 15 30 Celsius Installation/Installation Temperature setpoint for the current operating case
Group, RTA
Occupancy
Temperature
setpoint, mode
1 0 1 - Installation/Installation One-point control or two-point control of the temperature.
Group, RTA
Non-occupancy
Temperature
oset, cooling
2.5 0.5 10 Celsius Installation/Installation
Number of degrees above the set “Temperature setpoint”
that is permitted before cooling of the room occurs.
Group, RTA
Non-occupancy
Temperature
oset, heating
-2.5 -10 -0.5 Celsius Installation/Installation
Number of degrees below the set “Temperature setpoint”
that is permitted before heating of the room occurs.
Group, RTA
Non-occupancy
Temperature
setpoint
22 15 30 Celsius Installation/Installation Temperature setpoint for the current operating case.
Group, RTA
Non-occupancy
Temperature
setpoint, mode
1 0 1 - Installation/Installation One-point control or two-point control of the temperature.
Group, RTA Holiday
Temperature
oset, cooling
5 0.5 10 Celsius Installation/Installation
Number of degrees above the set “Temperature setpoint”
that is permitted before cooling of the room occurs.
Group, RTA Holiday
Temperature
oset, heating
-5 -10 -0.5 Celsius Installation/Installation
Number of degrees below the set “Temperature setpoint”
that is permitted before heating of the room occurs.
Group, RTA Holiday
Temperature
setpoint
20 15 30 Celsius Installation/Installation Temperature setpoint for the current operating case.
Group, RTA Morning
heating
Temperature
oset, cooling
3 0.5 10 Celsius Installation/Installation
Number of degrees above the set “Temperature setpoint”
that is permitted before cooling of the room occurs.
Group, RTA Morning
heating
Temperature
oset, heating
-3 -10 -0.5 Celsius Installation/Installation
Number of degrees below the set “Temperature setpoint”
that is permitted before heating of the room occurs.
Group, RTA Morning
heating
Temperature
setpoint
22 15 30 Celsius Installation/Installation Temperature setpoint for the current operating case.
Group, RTA Summer
night cooling
Temperature
oset, cooling
5 0.5 10 Celsius Installation/Installation
Number of degrees above the set “Temperature setpoint”
that is permitted before cooling of the room occurs.
Group, RTA Summer
night cooling
Temperature
oset, heating
-5 -10 -0.5 Celsius Installation/Installation
Number of degrees below the set “Temperature setpoint”
that is permitted before heating of the room occurs.
Group, RTA Summer
night cooling
Temperature
setpoint
20 15 30 Celsius Installation/Installation Temperature setpoint for the current operating case.
