Symbologies 12 - 61
UPC Composite Mode
UPC symbols can be “linked” with a 2D symbol during transmission as if they were one symbol. Three options are
offered for these symbols:
•
If UPC Never Linked is selected, UPC bar codes are transmitted regardless of whether a 2D symbol is
detected.
•
If UPC Always Linked is selected, UPC bar codes are only transmitted when the 2D portion is detected.
•
If Autodiscriminate UPC Composites is selected, the scanner determines if there is a 2D portion, then
transmits the UPC portion only.
UPC Never Linked
*UPC Always Linked
Autodiscriminate UPC Composites
