Maintenance, Troubleshooting & Technical Specifications 3 - 7
Scanner Signal Descriptions
Figure 3-1
Scanner Cable Pin-outs
Cable interface port
Interface cable
modular connector
Bottom of
scanner
PIN 1
PIN 10
