Accessories 3-5
• Charges the mobile computer’s Li-ion battery.
• Charges a spare Li-ion battery.
Battery Charging
The Single Slot Serial/USB cradle can charge the mobile computer’s main Li-ion battery and a spare Li-ion battery simultaneously.
Re-chargeable AAA batteries do not charge in the mobile computer when the mobile computer is placed in
the Single Slot Serial/USB cradle.
To charge the battery for your mobile device, battery and charger temperatures must be between +32° F and
+104° F (0° C to +40° C).
To charge the mobile computer:
1. Connect the Single Sot Serial/USB cradle to a power source.
2. Firmly press the mobile computer into the mobile computer slot. The mobile computer’s Charge LED indicates the mobile
computer battery charging status.
3. When charging is completed, hold the cradle with one hand and lift the mobile computer out of the cradle with the other
hand.
To charge the spare Li-ion battery:
1. Connect the Single Sot Serial/USB cradle to a power source.
2. Align the battery contacts as shown on the cradle. Note the polarity icon on the battery.
3. Insert the battery into the battery slot noting the battery polarity.
4. Gently press down on the battery to ensure proper contact.
The cradle spare battery charging LED (see Figure 3-1 on page 3-4) indicates the spare battery charging status. See Table 3-1 for
charging status indications.
To remove the spare battery, pull the battery away from the mobile computer slot and lift the battery out of the slot.
The Li-ion battery charges in less than four hours.
Table 3-1. LED Charging Status Indicators
LED Indication
Mobile Computer Charging (LED on mobile computer)
Off Mobile computer not in cradle; mobile computer not placed correctly; cradle is not
powered, or environment is outside the battery charging temperature range.
Slow Blinking Amber Mobile computer is charging.
Solid Amber Charging complete.
Spare Battery Charging (LED on cradle)
Off No spare battery in slot; spare battery not placed correctly; cradle is not powered,
or environment is outside the battery charging temperature range.
Slow Blinking Amber Spare battery is charging.
Solid Amber Charging complete.
