3.2 Technical specification
Dimensions(WxHxD)
110mm x 62mm x 142mm
weight
0.5kg
panel
Front panel：SS304，IP65；panel material：aluminum，IP42。
Load cell connector
Max 6pcs 350Ωload cells, or load with impedance over than58Ω.
Input signal：-20mV ~ +20mV。
A/D conversion
24 bits high resolution Σ-Δ Conversion with 200 Hz sample rate.
Resolution
Maximum display resolution ： 50000d ， Minimum sensitivity
0.2μv/d。
display
Upper window: 6 digits red 7-segment LED
，
word: 10.3mm
；
Lower window: 6 digits green 7-segment LED
，
word 7mm
；
Display refresh: 10Hz
；
Key board
4 membrane keys
Discrete input
Max 4 opto-isolated input settings.
Discrete output
Max 12 isolated MOSFET outputs, load capacity
30VDC/300mA(with overload pretection)。
communication
Isolated RS232 or RS485 (Set by internal jumper)
protocol
Continuous output format, print output, MODBUS-RTU
Application modes
BC360.A1
：
four materials batching.
BC360.C1/C2/C3
：
single material, two speed feeding control.
Recipe
Max 10 recipe records stored
Power supply
20–28 VDC，<200mA
Working
environment
temp：

10° ~ +40° C；humidity： 10% ~ 90%, non-condensing.
Storage environment
temp：

30° ~ +60° C；humidity： 10% ~ 90%, non-condensing
