1
、
All LED segments light on for 2 seconds.
2
、
Upper display shows software number, lower display shows version number. for example,
upper display shows [
000292
]
，
lower display shows [
V 1.5
].
3
、
enter into weighing display, if current load is under power-up zero range, the terminal execute
1
、
if F2.7 is set to 0, power-up zero is disable, the terminal display current weight based on last
working zero, if there is tare during last turn off, tare can be reserved and displayed in next turning
2
、
if F2.7 parameter is nonzero, and weight is within power-up zero range, the terminal execute
power-up zero operation. If current gross weight is over this setting power-up range the upper
display shows [
E0
], or show [- - - - - -] if the weighing signal is in motion.
3、If F6.10=1, the power-up zero is disabled and the terminal display current weight based on last
working zero during turning off.
