2 Function & Features
BC360 weighing indicator specially used for multiple ingredients batching during industry
control. This terminal is a weighing control expert on packing scale, drum-filling scale, bulk
weighing system, dosing and batching applications which widely suitable for such as metallurgy,
chemical industry, construction material industry, painting, cereal & feed, beverage, and in/out port
etc. industrial fields.
BC360 main features
：
 Compact panel enclosure and easy-mount structure
 Four material batching control independently
 Store 10 recipes.
 24 bits high resolution SIGMA-DELTA AD conversion with 200 Hz effective output rate
 Automatically spill correct
 Automatically accumulate and error analysis
 12 MOSFET output, 3 redundancy available.
 standard isolated RS232 / RS485 connection
 support MODBUS RTU connection
 Semi-automatic mode can support feeding randomly
 1/2 speed feeding available
3 MODE & TECHNICAL SPECIFICATIONS
3.1 MODE
MODE
description
BC360.A1
Four material batching;4 inputs12 outputs; RS232/RS485, DC24V
BC360.C1
One material setpoint control, 1 input,4 output,RS232/RS485 DC24V
BC360.C2
One material setpoint control, 1 input,4 outputs,
RS232/RS485, 4~20mA/0~10V analog output. DC24V
BC360.C3
One material setpoint control, 1 input,4 output,
RS232/RS485, ProfibusDP Interface. DC24V
