SYMC BC360 User Manual

41
10. OPTION -- ANALOG OUTPUT CONFIG (F4)
！
The parameter group F4 is accessable only in the model BC360.C2 in which the
analog output option board is installed.
MENU
parameter
Description
F4.1
Data map
0: gross weight
1: display weight
F4.2
Output mode
0：4~20mA output.
1
：
0~10V output.
AL _nN
4mA/0v
Coarse-tune
Press [Enter] key entering into tuning status, the display
shows the internal reference value at analog zero.
Press [Tare] to increase the displayed value or press
[Select] to decrease the value until the output value equal
with 4mA/0v.
Press [Enter] to save the change or press[Zero] to exit
without save.
Note: user can watch the out value by means of
multimeter or connected working PLC/DCS.
AL _n
4mA/0v
Fine-tune
AL _
4mA/0v
Tiny-tune
AH _nN
20mA/10v
coarse-tune
Press [Enter] key entering into tuning status, the display
shows the internal reference value at analog
span(20mA/10v).
Press [Tare] to increase the displayed value or press
[Select] to decrease the value until the output value equal
with 4mA/0v.
Press [Enter] to save the change or press[Zero] to exit
without save.
Note: user can watch the out value by means of
multimeter or connected working PLC/DCS.
AH _n
20mA/10v
Fine-tune
AH _
2mA/10v
Tiny-tune
Connection with Current output(4~20mA) mode
Connection with Voltage output(0~10v) mode
IGND
Iout
Vout
VGND
+
-
