SYMC BC360 - Formula Parameter Setting [Setpt]

28
6.3 Formula parameter setting [SEtpt]
Menu
Instruction
Operation instruction
[M1]
twinkle
Material 1
formula setting
Lower window shows target value of material 1, press
[ENTER] to edit the setpoints of material 1.
target
Material 1
target weight
At the beginning of material 1 feeding, the terminal first
fast feeds weight to setpoint
（
Target - Fine
）
. Then
slowly feeds weight to setpoint (Target - Preact），then
weight terminal send a signal of closing slow feeding.
For example: target is 100kg, preact value is 1.5kg, so
weight terminal will send a signal of closing feeding
when it reached 98.5kg. The preact value can be pre-set
manually, or automatically fixed by weight terminal
during batching.
The setpoint value validity rules: (Target)≥(Fine) ≥
(Preact)
，
else terminal will show “Err”.
Fine
Material 1 fine
feed setpoint
Preact
Material 1 spill
setpoint
[M2]twink
le
Material 2
formula setting
！when setting parameter F6.8>1，this menu appears.
target
Material 2
target weight
Fine
Material 2 fine
feed setpoint
Preact
Material 2 spill
setpoint
[M3]twinkle
Material 3
charging lead
！when setting parameter F6.8>2, this menu appears.
target
Material 3
target weight
Fine
Material 3 fine
feed setpoint
Preact
Material 3 spill
setpoint
[M4]twinkle
Material 4
charging lead
！
when setting parameter F6.8=4
时，
this menu appears.
target
Material 4
target weight
Fine
Material 4 fine
feed setpoint
Preact
Material 4 spill
setpoint
