SYMC BC360 User Manual

44
x
Select 3
1
2
x
Load Preset Tare
2
3
x
Clear Tare Command
3
4
x
Pushbutton Tare
Comand
3
5
x
Print
3
6
x
Zero
3
7
x
Reserved
8
x
Reserved
9
x
Cal Zero Cmd.
10
x
Cal Span Cmd.
11
x
Load Zero Tol.
4
12
x
Load Fine Feed
4
13
x
Load Spill value
4
14
X
Load Target value
4
15
Word0 is signed integer value, this value will be written into terminal according to bit 3 ~
bit 15 value in word 1.
1
、
Select1,2,3 definition
The 3 select bits determine what kind of data be sent to PLC.define as below:
Select
bit2,bit1,bit0
True value
Data source
0,0,0
0
Gross Wt.
0,0,1
1
Net Wt.
0,1,0
2
Display Wt.
0,1,1
3
Tare Wt.
1,0,0
4
Target
1,0,1
5
Reserved
1,1,0
6
Increment code
1,1,1
7
Total Wt.
Increment code definition:
Word0
Increment
0x0015
0.0001
0x0025
0.0002
0x0055
0.0005
0x0014
0.001
0x0024
0.002
0x0054
0.005
0x0013
0.01
0x0023
0.02
0x0053
0.05
0x0012
0.1
0x0022
0.2
