12713140-002-2 Revision E – October 2006 SSU-2000e User’s Guide 159
Chapter 6 Clock Module Reference Data
Communications Module
Alarms are elevated from MINOR to MAJOR to CRITICAL on a per module basis
with a user-set time, from 60 to 500,000 seconds; the default is 86,400 seconds, or
one day. The elevation time is stored in each module.
You can select delay periods for software alarms from 0 to 86400 seconds. Changing
the delay period generates an event. The setting is stored in each module
.
Table 6-11 lists the Communications module alarms.
Configuration Data
Table 6-12 lists the factory default settings and ranges for the communication
module software configuration options.
Note: If the original value is set to IMMED (–1), it means this error
delay is not allowed to change and will happen immediately.
Table 6-11. Communications Module Alarms
ID Description
Alarm
Level
Error Delay
Default
Error Delay
Settable
0x0 Backplane Communication Errors MINOR 5 sec Yes
0x1 Mastership Problems MINOR 5 sec Yes
0x2 Loss of Power A MINOR Immediate No
0x3 Loss of Power B MINOR Immediate No
0x4 SPI Watchdog Timeout MAJOR Immediate No
0x5 Shelf 2 Communications CRITICAL 0 sec Yes
0x6 Shelf 3 Communications CRITICAL 0 sec Yes
0x7 Shelf 4 Communications CRITICAL 0 sec Yes
0x8 Shelf 5 Communications CRITICAL 0 sec Yes
0x9 Module Removed MINOR 5 sec Yes
Table 6-12. Communications Module Configuration Data
Configuration Setting Factory Default
Unit Name SSU-2000e
User List configurations Maximum of 25 users including four built-in users
