12713140-002-2 Revision E – October 2006 SSU-2000e User’s Guide 209
Chapter 8 Output Module Reference Data
2048 kHz Output Module
E1/2048 kHz Output Module Software Options
The factory default setting and range for all E1/2048 kHz Output module software
parameters are listed in
Table 8-10
.
2048 kHz Output Module
This section provides operating instructions and software provisioning procedures
for the 2048 kHz Output module (part number 23413159-000-0). It also contains
default provisioning settings, and procedures for connecting to the SSU-2000e in
order to enable, provision, and disable the module.
Functional Overview
The 2048 kHz Output module receives a set of three (four if installed in an
expansion shelf) 4 kHz clocks from the Clock modules and uses these clocks to
develop an 8.192 MHz phase-locked signal. This phase-locked signal is then used
to generate 20 sets of 2048 kHz clock outputs.
Table 8-10. E1/2048 kHz Output Module Configuration
Configuration Setting Factory Default Range
Signal Type E1 E1 | 2048
Framing Mode CAS CAS | CCS
Zero suppression On On | Off
SSM On On | Off
CRC On On
SSM Bit Position 8 4 | 5 | 6 | 7 | 8
Port Output (per port) Enabled Enable | Disable
Bypass Enable Enable | Disable
Port Label (per port) Null Up to 20 printable characters;
0 is string terminator
Alarm Elevation 86 400 s 1 – 500 000 s
Squelching 0 1–16, 0 is disabled
