12713140-002-2 Revision E – October 2006 SSU-2000e User’s Guide 87
Chapter 2 Installing the SSU-2000e
After Turn-Up
Normal System Indications During Turn-Up
As the system powers up and begins normal operation, the indicators on the front of
all installed Output modules should go through the following sequence:
The POWER indicator turns green when power is applied to the unit and stays
green.
The STATUS indicator blinks green and amber for approximately 10 to 15
seconds and then stays green.
The SOURCE indicator turns green for source clock, amber for not source
clocks, and off for non-existent clocks.
The POWER indicator and both –48/60 VDC indicators on the installed Buffer
modules should turn green and stay green.
After Turn-Up
After completing the turn up procedures:
Assign a System Administrator and any additional users to the system using the
procedures in Adding An Administrator User, on page 95.
Make any required changes to the factory default configuration settings as
described in Chapter 3, Provisioning and Operating the SSU-2000e.
Complete the commissioning tests in Chapter 4, Commissioning the SSU-2000e,
to ensure that the system is functioning properly.
Refer to Chapter 5, Maintenance and Troubleshooting to clear any system
alarms that might occur.
This completes the turn-up procedures. See Chapter 3, Provisioning and Operating
the SSU-2000e, for instructions on connecting to the SSU-2000e and assigning a
system administrator and additional users (system is password protected). Then
refer to Chapter 4, Commissioning the SSU-2000e, for test procedures to ensure
the system is functioning properly, or to Chapter 5, Maintenance and
Troubleshooting, to clear any persistent system alarms.
