12713140-002-2 Revision E – October 2006 SSU-2000e User’s Guide 181
Chapter 7 Input Module Reference Data
1-Port and 3-Port DS1 Input Modules
Configuration Options
The DS1 input module maintains factory default and current user configuration
information in nonvolatile memory. This information is retrieved at power up and can
be modified by commands from the Communications module. In the event that the
current user configuration cannot be used, the module automatically reverts to
factory defaults.
Software Options
The factory settings and ranges for all DS1 Input module software parameters are
listed in Table 7-8.
Table 7-8. DS1 Input Module Configuration
Configuration Setting Factory Default Range
Framing Enabled On/On/Off On/Off
Input Frequency (for
unframed signals)
10MHz 1MHz, 1.544MHz, 2.048MHz, 5MHz, 10MHz
Framing Type ESF D4 or ESF
Zero Suppression On On/Off
CRC Off On/Off
SSM Off On/Off
Provisioned PQL 3/4/3 1–16
Priority 0 0–10 (0 = Monitor)
Cesium Fault Nominal Low Low/High/Off
Input Signal Error Limit 10 seconds 1–100 for LOS and AIS
1–10000 for BPV, CRC, and OOF
MTIE T10 Limit1 325/1000/325 0 to 100000
MTIE T10 Limit2 330/1010/330 0 to 100000
MTIE T100 Limit1 550/2000/550 0 to 100000
MTIE T100 Limit 2 560/2010/560 0 to 100000
MTIE T1000 Limit1 1010/2000/1010 0 to 100000
MTIE T1000 Limit2 1020/2010/1020 0 to 100000
MTIE T10000 Limit 1 1100/2835/1100 0 to 100000
MTIE T10000 Limit 2 1110/2840/1110 0 to 100000
MTIE Limit 1 Alarm Mode Minor Ignore, Report, Minor, Major, or Critical
