Chapter 2 Installing the SSU-2000e
Handling Modules
76 SSU-2000e User’s Guide 12713140-002-2 Revision E – October 2006
ICS command:
Type
CONFIG 1A3 DISABLE, then press Enter.
TL1 command:
DISC-MODULE::S1A3:123;
4. Loosen the captive screws located at the top and bottom of the module front
panel.
5. Pull up on the top extractor and down on the bottom extractor to unseat the
module from the connector on the backplane.
6. Slide the module out of the shelf.
7. Insert the new module into slot 3 of the main shelf. Tighten the captive screws
on the front panel of the module. Wait for the “
module installed” message to
appear.
8. Enable the module using either TL1 or ICS commands:
ICS command:
Type
CONFIG 1A3 ENABLE, then press Enter.
TL1 command:
ACT-MODULE::S1A3:123;
9. Verify that the module is entered in the registry:
ICS command:
Type
CONFIG, then press Enter.
TL1 command:
RTRV-INV:::123;
Disabling a Module
Use this command to temporarily disable a module without removing it from the
SSU-2000 registry. All outputs from the disabled module will turn off, unless a
summer adapter is installed on the I/O connector on the rear panel of the shelf. The
example commands are for slot 3 in the main shelf.
Note: Be sure that the I/O Adapter port is of the proper type and
impedance for the new module.
Caution: To avoid possible damage and intermittent failures, ensure
that you have completely inserted the module into the system and
that you have securely tightened the captive screws.
