Chapter 8 Output Module Reference Data
RS-422 Output Module
218 SSU-2000e User’s Guide 12713140-002-2 Revision E – October 2006
Use the Alarm command to display the alarm information for a given module; the
display includes all RS-422 Output module alarms, including Alarm #14,
Squelching. Use the Alarm command to provision these alarms to Ignore, Report
Only, Minor Alarm, Major Alarm (default), or a Critical Alarm. Refer to the
SSU-2000e Technical Reference for more information on using the Alarm
command.
SSU+>al 2a10
2002-07-04T10:25:31 ID: SSU2000 Name: SSU
Output # Alarm Status Level(*=Elev) Ports
------- ---- ------------------ --------------- ------------- ---------
2A10 (00) Hdw Config Ok Major
2A10 (01) COnfiguration Ok Major
2A10 (02) Clk-A Ok Major
2A10 (03) Clk-B Ok Major
Table 8-14. Identifying Failed Ports from the Hex Digit
Hex Value
Digit 1
Digit 2
Digit 3
Digit 4
Digit 5
Port
1
5
9
13
17
Port
2
6
10
14
18
Port
3
7
11
15
19
Port
4
8
12
16
20
0––––
1–––X
2––X–
3––XX
4– X – –
5– X – X
6–XX–
7–XXX
8X–––
9X––X
AX – X –
BX – X X
CXX––
DXX–X
EXXX–
FXXXX
