Symmetricom SSU-2000e User Manual

Chapter 8 Output Module Reference Data
E1/2048 kHz Output Module
204 SSU-2000e User’s Guide 12713140-002-2 Revision E – October 2006
Use the Alarm command to display the alarm information for a given module; the
display includes all E1/2048 kHz Output module alarms, including Alarm #10,
Squelching. Use the ALARM command or the SET-PRMTR-OUTE12048 command
(described in the SSU-2000e Technical Reference) to provision these alarms to
Ignore, Report Only, Minor Alarm, Major Alarm (default), or a Critical Alarm.
SSU+>al 2a10
2002-07-04T10:25:31 ID: SSU2000 Name: SSU
Output # Alarm Status Level(*=Elev) Ports
------ ---- ----------------- -------------- ------------- --------
1A06 (00) Hdw Config Ok Major
1A06 (01) Configuration Ok Major
1A06 (02) Clk-A Ok Major
1A06 (03) Clk-B Ok Major
1A06 (04) Clk-C Ok Major
1A06 (05) Clk-D Ok Major
1A06 (06) Clk Selected Ok Major
1A06 (07) VCXO Ok Major
1A06 (08) PLL Ok Major
1A06 (09) Sync Ok Major
1A06 (10) Squelch Ok Major
1A06 (11) PortFlt Ok Major
SSU->
Provisioning the Squelch Parameter
To view or provision the squelch using ICS or TL1 commands, see the SSU-2000e
Technical Reference
.
Bypass Clock (CLK-C) Alarms
The SSU-2000e has many configuration options. In order for the system to generate
the CLK-C used by the E1/2048 kHz Output module, you must install one of the
following Input modules and connect an input signal to the module: DS1, E1, or CC.
If the SSU-2000e has only GPS Input module(s), then set the Bypass mode to OFF
to prevent the Output modules from generating the CLK-C alarm (alarm 4).
DXX–X
EXXX–
FXXXX
Table 8-7. Identifying Failed Ports from the Hex Digit (Continued)
Hex Value
Digit 1
Digit 2
Digit 3
Digit 4
Digit 5
Port
1
5
9
13
17
Port
2
6
10
14
18
Port
3
7
11
15
19
Port
4
8
12
16
20
