TMSL 097-45018-02 Issue 3: Mar 96
Page 50
RETRIEVE ALARMS (Contd)
aid: For RTRV-ALM-EQPT:
EXPANS = expansion shelf
FUSE-1 = fuse A
FUSE-2 = fuse B
MASTER = master shelf
MRC-1 = Multi-Reference Controller A
MRC-2 = Multi-Reference Controller B
PSM-x = Precision Sync Monitor card (x = 1 to 9)
MIS = Maintenance Interface, System
CLK-1 = Stratum clock unit A
CLK-2 = Stratum clock unit B
GTI-1 = GTI installed in the A slot
GTI-2 = GTI installed in the B slot
SYSTEM = all clocks have failed
aid: For RTRV-ALM-T1
:
MRC-1-x = Multi-Reference Controller A (x = span 1 to 4 or ALL)
MRC-2-x = Multi-Reference Controller B (x = span 1 to 4 or ALL)
PSM-x-y = Precision Sync Monitor card (x = 1 to 9, y = span 1 to 4
or ALL)
ntfcncde: CR = critical alarm
MJ = major alarm
MN = minor alarm
condtype AIS = alarm indication signal
FA = fuse or power fail
FRNGSYNC = clock is in the freerunning mode
FSTSYNC = clock is in the fast-converge mode
HLDOVRSYNC = clock is in the holdover mode
INT = card has failed
LOS = loss of signal
SFI = loss of stratum input to MRC
SLTMSIG = input references are unlocked
SYNC = input reference has failed
SYNCCLK = output port has failed
SYNCPRI = loss of all primary timing references
SYNCSEC = loss of all secondary timing references
TBPV = threshold for BPVs has been exceeded
TCRC = threshold for CRCs has been exceeded
TOOF = threshold for OOFs has been exceeded
condtype For PSM only:
MTIE1 = maximum time interval error at 1 second
MTIE4 = maximum time interval error at 4 seconds
MTIE16 = maximum time interval error at 16 seconds
MTIE64 = maximum time interval error at 64 seconds
MTIE128 = maximum time interval error at 128 seconds
MTIE512 = maximum time interval error at 512 seconds
MTIE900 = maximum time interval error at 900 seconds
TVAR1 = time variance error at 1 second
