              22/220 Series Controller Application Manual
Software Installation、Data Backup/Restore–73
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
10.116.36D, 10.116.39: Failures fixed.The Tool Table Data is moved to "Kernel
Data" item.
M Code Group (ScanTable.dat):
10.116.24Q, 10.116.34:Provides backup and restore file using "Registry
(Registry.dat)"
10.116.24R, 10.116.35:Backup/restore of these files will fail due to the
unmatched directory after changing the file position.
10.116.24X, 10.116.36D, 10.116.39:Failures fixed.The M Code Group data is
moved to "Kernel Data" item.
For I/O Chart Data, versions 10.116.38F, 10.116.54D, 10.118.0B and later are recommended.
Backup Option Changes:
I/O Chart (IoMap_Customer.xml):
10.116.38A, 10.116.53, 10.117.53: Provides the I/O chart setup funtion, the data is
stored in "Kernel Data" (SysData)
10.116.38F, 10.116.54D, 10.118.0B, 10.118.2: The file position of I/O chart in controller
is changed, also the I/O Chart data (IOMap) is able to be selected for backup
individually.
For I/O Chart MB files generated before the change, please run the backup
again in the new version. The back up/restore between different versions is
incompatible.
Limitations
Front/back stage connection does not support SB restore.
For front/back stage connections with PC as front stage, versions 10.118.10, 10.118.0J(included) and
later support MB backup and restore, the backup and restore files are always backstage files.
System Restore
Path
Eight Key: F10 Next →F4 System Admin.→ F3 Restore Sys.
FiveKey:F10 Next → F4 System Admin.→ F3 RestoreSys.
Function
This button is used to restore system data of controller. There are two types of restore file source:
Syntec Backup (SB) and Maker Backup (MB) files.
Front/back stage connection does not support SB backup and restore.
For front/back stage connections with PC as front stage, versions 10.118.10, 10.118.0J(included) and
later support MB backup and restore, the backup and restore files are always backstage files.
Use MB backup files to restore, it's able to select individual items
After Version 10.116.34, boot image restoreis provided.
Versions after 10.116.24V, 10.116.36B, 10.116.37,10.117.37 (not include): for front/back stage
connections withHandheld pendant CE as front stage, the customized HMI (OCRes) can be
restored ONLY to front stage.
Versions after 10.118.66M, 10.118.70F: If the boot picture item is selected, the image
specification will be checked. If the check fails, an error message will pop up and the restore
operation will be interrupted
To restore system using SB backup files, the user can only run a complete restoration.
In versions 10.116.34 and later, if there is a boot image in SB backup file, a windowwill appear
to ask whether to restore the image as well.
Versions after 10.118.66M, 10.118.70F: The image specification will be checked first. If the
check fails, an error message will pop up and the restoration of other items will continue.
Operation
Enter "Restore Sys." screen and select the restoring backup file and press "Next".
