TB8100 Service Manual Power Amplifier Fault Finding 171

Note The information in this table is extracted from the TB8100 Spec-

ifications Manual. Refer to the latest issue of this manual

(MBA-00001-xx) for the most up-to-date and complete specifi-

cations.

Table 8.6 Supply current specifications

Test Lim its

Supply Current - 12V PA

Standby

Transmit

5W PA at 5W

50W PA at 50W

Maximum Typical

200mA 165mA

1.5A 1.2A

10.2A 9.2A

Supply Current - 28V PA

Standby

Transmit - B, C and H Bands

5W PA at 5W

50W PA at 50W

100W PA at 100W

Transmit - K and L Bands

5W PA at 5W

50W PA at 50W

100W PA at 100W

Maximum Typical

50mA 42mA

600mA 530mA

5A 4.2A

10A 8.3A

600mA 530mA

5A 4.2A

11A 8.5A

a. measured at 12.5VDC input

b. into a 50Ω load

c. 50W model unavailable in L band
