19 Subrack Servicing
This chapter lists the spare parts available for the TB8100 subrack at the time
this manual was published.
â– Spare subrack assemblies are listed in Table 19.1.
â– Mechanical parts and cables are listed as follows:
â– Figure 19.1 on page 289 identifies the mechanical parts used in
the front panel assembly
â– Figure 19.2 on page 290 identifies the mechanical parts used in
the subrack assembly
â– Figure 19.3 on page 291 and Figure 19.4 on page 292 identify the
cables used in single and dual base stations
â– Figure 19.5 on page 293 identifies the cables and mechanical parts
used in the multi-reciter subrack.
Other items may become available as spares at a later date. Consult your
nearest Tait Dealer or Customer Service Organisation regarding the
availability of specific items.
Table 19.1 Spare subrack assemblies
Description Spares Code
subrack (complete with guide rails and retaining clamps) TBA-SP-RACK
front panel (no fans or labels)
front panel (complete with fans; no labels)
front panel (PA fan only; no labels)
front panel (PMU fan only; no labels)
TBA-SP-F2130
TBA-SP-F2132
TBA-SP-F2135
TBA-SP-F2136
subrack interconnect board single base station
dual base station
multi-reciter
TBA-SP-K22C0
TBA-SP-K22C2
TBA-SP-K22C6
