TB8100 Service Manual Reciter Fault Finding 97

Table 3.3 Final tests for the exciter

Test Lim its

Switching Range

B and C Bands

H Band

K Band

L1 Band

L2 Band

8MHz

10MHz

762MHz to 776MHz and 850MHz to 870MHz

852MHz to 854MHz and 928MHz to 930MHz

927MHz to 941MHz

Frequency Stability

Hardware Version 0.02 (or earlier)

Hardware Version 0.03 (or later)

±1ppm –30°C to +60°C (–22°F to +140°F)

±0.5ppm –30°C to +60°C (–22°F to +140°F)

Power Output +11dBm ±2dB

Microphone Input

Input Level Range

Impedance

Compressor

Attack Time

Decay Time

Dynamic Range

Distortion

a. 60% modulation at 1kHz

80dBSPL to 115dBSPL

600Ω

10ms

800ms

35dB

≤3%

Line Input - Balanced

Input Level Range

Impedance

b. 60% modulation at 1kHz

–20dBm to +10dBm

600Ω balanced

Line Input - Unbalanced

Input Level Range

Impedance

0.3Vpp to 3Vpp

>10kΩ
