Takeuchi TB216 User Manual

3-13
OperatiOn
When the dozer blade is in front of the
operator’s seat:
To move forward:
Tilt the levers forward.
To move backward:
Tilt the levers backward.
OPERATING THE MACHINE
When the dozer blade is behind the
operator’s seat:
To move forward:
Tilt the levers backward.
To move backward:
Tilt the levers forward.
Traveling in 2nd (High) speed
Press the travel speed switch on the right
travel lever to switch to 2nd (high) speed,
and press it again to return to 1st (low)
speed.

Takeuchi TB216 Specifications

General

Engine Make	Yanmar
Engine Model	3TNV70
Transport Width	980 mm
Bucket Capacity	0.04 m³
Maximum Reach	4, 040 mm
Max Reach at Ground Level	3, 980 mm
