Takeuchi TB216 User Manual

3-14
OperatiOn
Pivot turn
Turning to the left when stopped:
To turn forward to the left:
Tilt the right lever forward.
To turn backward to the left:
Tilt the right lever backward.
To turn to the right, operate the left lever in
the same way as for the right lever.
Turning to the left while traveling:
To turn left while traveling forward:
Set the left lever to neutral.
To turn left while traveling backward:
Set the left lever to neutral.
To turn to the right while traveling, operate
the right lever in the same way as for the left
lever.
Spin turn
OPERATING THE MACHINE
To spin left:
Tilt the left lever backward and the right
lever forward.
To spin right:
Tilt the right lever backward and the left
lever forward.

Takeuchi TB216 Specifications

General

Engine Make	Yanmar
Engine Model	3TNV70
Transport Width	980 mm
Bucket Capacity	0.04 m³
Maximum Reach	4, 040 mm
Max Reach at Ground Level	3, 980 mm
