User guide Specifications
127
Interface specifications
Parallel interface bidirectional
Type of data transmission 8-bit parallel interface (Centronics compatible) IEEE-1284; Nib-
ble mode
Transmission rate Max. 30 KHz
Signal status Low: 0.0 V to +0.4 V
High: +2.4 V to +5.0 V
Connection cable Material: AWG 28 at least
Length: up to 2.0 m
Twisted-pair cable with double-shield,
acc. IEEE Std 1284 – 1294
Voltage supply of external devices
on pin 18
U = +5 V ±10%
I = 0.5 A
max
Interface connections Printer side:Amphenol 57-40360, 36-pin (or compatible)
Cable side:Amphenol 57-30360, 25-pin (or compatible)
Ethernet-Schnittstelle Onboard 10/100BaseT Ethernet-RJ45 with 2 LEDs
Transmission rate 100 Mbps / Full Duplex
Supported protocoles TCP/IP, Telnet
Network print protocoles LPR/LPD, RAW Port, FTP
IP address designation DHCP, BootP and manually over the control panel
Connection cable RJ45
Network print management
protocoles
HTTP, HTML, SNMP
Capacity of data buffer 8 MB
