User guide Printer at a glance

5

Paperway

* Not available on some models.

Single sheet

Tractor 1

Tractor 2

Tractor 3

` Fanfold paper mode

` Single sheet mode

Standard printer: Tractor 1

Single sheet*

Options: Tractor 2

Tractor 3, only for

2T model, integrated

Single sheet feeder front

(ASF-F)

Single sheet feeder rear

(ASF-R)
